PORTABLE SPIROMETER SP-80B
PORTABLE SPIROMETER SP80B
Small, portable spirometer for examining lung function.
The high definition screen directly displays measured parameters such as Forced Vital Capacity (FVC), Maximum Expiratory Volume in One Second (FEV1), FEV1/FVC Ratio between Maximum Expiratory Volume in One Second (FEV1) and Forced Vital Capacity (FVC), Peak Expiratory Flow (PEF), Forced Expiratory Flow at 25% of FVC (FEF25), Forced Expiratory Flow at 50% of FVC (FEF50), Forced Expiratory Flow at 75% of FVC (FEF75), and Forced Expiratory Flow 25~75% of FVC (FEF2575).
High accuracy and repeatability. Suitable for hospitals, clinics, families for routine testing.
- management of patient information (height, age, gender, etc.)
- flow-volume and volume-time graph visualisation
- trend graph display
- health status indication
- calibration function
- data can be stored, deleted, loaded and reviewed
- alarm for exceeding volume and flow limits
- indicates exhalation within 6 seconds
- data transmission via Bluetooth or USB cable
- automatic switch-off within 2 minutes
Supplied with USB cable, 2 disposable mouthpieces, PC software (GB, IT, ES, PT) and manual GB, FR, IT, ES, PT.
DE, PL, RO, SE, GR available at www.gimaitaly.com Method: Turbine
Parameters: 8 FVC-related parameters (FVC, FEV1, FEV1/FVC, PEF, FEF 25, FEF 50, FEF 75, FEF 2575)
Volume range: 0~10 l ± 3% or 0.05 l (whichever is greater)
Flow range: 0~16 l/s ± 5% or 0.2 l/s (whichever is greater)
