OXY-CAPNOGRAPH PC-900B

Innovative portable capnograph and oximeter, ideal for monitoring the most severe conditions of intubated and non-intubated patients.

It provides both SpO2 and heart rate measurements.
The special MoveOxy™ technology ensures effective readings even in case of patient movement or weak pulse signal.
Shows trend graph and plethysmographic waveform.
- 3.5" TFT display showing EtCO2, rr and SpO2, pr
- lung pressure and temperature compensation (BTpS compensation)
- graphic trend storage up to 24 hours
- USB cable for data transfer to PC
- wireless module for connection to Bluetooth printer

Dimensions: 70x160xh 40 mm.
Weight: 600
Internal languages: GB, IT, ES, NL, DE, FR. EtCO2
EtCO2/CO2 range: 0-150 mmHg (0-20 kPa, or 0-20% (V/V))
Accuracy: when mmHg 0-40 >41-70 >71-100 >101-150 ±2 mmHg ±5% ±8% ±10%
Update: Every breath, every 10, 20 or 30 sec selectable

Breathing
Time: 3-150 breaths/min
Flow: 50 2 water filters
USB cable
Support base
2 sampling lines
CO2 nasal cannula
Manual in GB, IT
2 airway adapters
Silicone protector
SpO2 sensor
Carrying bag
