SUNLIGHT MINIOMNI ULTRASOUS BONE DENSITOMETER FOR OSTEOPOROSIS EVALUATION with CM probe + software

SUNLIGHT MINIOMNI™ ULTRASOUND DENSITOMETER FOR OSTEOPOROSIS EVALUATION with CM probe + MINIOMNI software

The Sunlight MiniOmni™ bone sonography system is an exceptionally cost-effective professional solution for the early diagnosis of osteoporosis, enabling reliable, accurate, non-invasive and safe assessment of bone density. Ultra-compact and ultra-light, easy and intuitive to use, practical USB port for connection to PCs and laptops running Windows™ 10 and higher. Suitable for use in any doctor's office, clinic, pharmacy, annual check-up centre or other point of sale.

Proven accuracy
MiniOmni™ is based on Omnipath™ quantitative ultrasound technology, which detects the speed of ultrasonic waves along the axis of maximum bone force, eliminating soft tissue effects and allowing for accurate results proven in thousands of facilities worldwide.

Proven safety
Non-invasive and radiation-free

Fast results
- no warm-up and calibration required
- immediate audio confirmation of correct measurement
- patient screening in minutes
- easy and quick to learn thanks to integrated training module

easily interpretable report in A4/letter format
- various ethnic reference databases for accurate results: Caucasian, Asian, Chinese, North and Latin American, European
- clear colour reports, easy to read and interpret
- patient data and history of findings
- gender and age (0 to 90 years) are taken into account
- T-score and Z-score compliant with WHO requirements

Very economical, quick return on investment
- no running costs, no routine maintenance, no consumables, no calibration

Optional Multi-Site licence (56805) for measurements at various skeletal sites
Allows measurement from various skeletal sites: radius, phalanx, tibia and metatarsus. The flexibility of the multi-site test improves the identification of osteoporosis points, as well as being able to test patients on whom it is difficult to assess certain skeletal sites.

- maximum convenience for the examiner, no need to bend over
- maximum convenience for the patient, no need to remove shoes
- ideal for immobile patients
- correlation of each site with osteoporosis is checked Method of measurement: ultrasonic wave speed (SOS)
Technology: Omnipath® axial ultrasound transmission
Probe frequency: 1.25 MHz
Measurement accuracy: 0.25 to 0.5%
Measurement time: approx. 1 minute per skeletal site
Power supply: 7.5V 1.5 A
Power consumption: 0.4 A
Dimensions: 140x140xh 223 mm (excluding probe holder)
Weight: 1 kg
Protection: type BF applied part, internal power supply with requirements for Class I or Class IS ultrasonic probe CM
Handrest
Radio/Tibia meter
Power supply 100-240 V and cable
Dermatological pen
USB connection cable
Ultrasound gel
MiniOmni software installation CD
System quality control dummy
User guide GB, EN
